1997 Walter Helitronic Mini Power
1997 Walter Helitronic Mini Power
Description
Suitable for regrinding and making new wood and metalworking tools of all kinds. Accessories: Software package 1 (cylindrical tools with sharp edges, corner and full radius) Software package 2 (conical-spiral tools with sharp edges, corner and full radius) Software package 3 (drills and step drills) Software package 4 (step tools) Software package 6 (woodworking tools) Software package 13 (reamers) Software package 16 (warm-up program), Software package 7/37 (profiles) Software package 27 (free programming) Heliflute & Cone chip space calculation program pneumatic workpiece clamping, automatic central lubrication, automatic fire extinguishing device, measuring probe
Specifications
| Manufacturer | Walter |
| Model | Helitronic Mini Power |
| Year | 1997 |
| Condition | Used |
| Stock Number | Mini_Pwr1997 |
| X - axis longitudinal movement | 350 mm |
| Y axis vertical movement | 200 mm |
| Z-axis transverse movement | 470 mm |
| C-axis rotary table swivel range | + / - 200° |
| Workpiece holder | ISO 50 |
| Center height (with/without top table) | 130 / 160mm |
| Max. Workpiece diameter | 100 mm |
| max. workpiece length | 270 mm |
| max. grinding wheel diameter | 150 mm |
| Drive power grinding spindle | 7 kW |
| Grinding spindle speed continuously variable | 0 - 9500 rpm |
| Connected load | 400V / 50Hz / 25kVA |
| weight | approx. 2600 kg |
| mass | approx. 2600 kg |
| Dimensions W x D x H = | 1800 x 2550 x 2300 mm |
| colour | grey RAL 7035 / 7043 |
